#define | IFT_OTHER 0x1 /* none of the following */ |
| |
|
#define | IFT_1822 0x2 /* old-style arpanet imp */ |
| |
|
#define | IFT_HDH1822 0x3 /* HDH arpanet imp */ |
| |
|
#define | IFT_X25DDN 0x4 /* x25 to imp */ |
| |
|
#define | IFT_X25 0x5 /* PDN X25 interface (RFC877) */ |
| |
|
#define | IFT_ETHER 0x6 /* Ethernet CSMA/CD */ |
| |
|
#define | IFT_ISO88023 0x7 /* CMSA/CD */ |
| |
|
#define | IFT_ISO88024 0x8 /* Token Bus */ |
| |
|
#define | IFT_ISO88025 0x9 /* Token Ring */ |
| |
|
#define | IFT_ISO88026 0xa /* MAN */ |
| |
|
#define | IFT_STARLAN 0xb |
| |
|
#define | IFT_P10 0xc /* Proteon 10MBit ring */ |
| |
|
#define | IFT_P80 0xd /* Proteon 80MBit ring */ |
| |
|
#define | IFT_HY 0xe /* Hyperchannel */ |
| |
|
#define | IFT_FDDI 0xf |
| |
|
#define | IFT_LAPB 0x10 |
| |
|
#define | IFT_SDLC 0x11 |
| |
|
#define | IFT_T1 0x12 |
| |
|
#define | IFT_CEPT 0x13 /* E1 - european T1 */ |
| |
|
#define | IFT_ISDNBASIC 0x14 |
| |
|
#define | IFT_ISDNPRIMARY 0x15 |
| |
|
#define | IFT_PTPSERIAL 0x16 /* Proprietary PTP serial */ |
| |
|
#define | IFT_PPP 0x17 /* RFC 1331 */ |
| |
|
#define | IFT_LOOP 0x18 /* loopback */ |
| |
|
#define | IFT_EON 0x19 /* ISO over IP */ |
| |
|
#define | IFT_XETHER 0x1a /* obsolete 3MB experimental ethernet */ |
| |
|
#define | IFT_NSIP 0x1b /* XNS over IP */ |
| |
|
#define | IFT_SLIP 0x1c /* IP over generic TTY */ |
| |
|
#define | IFT_ULTRA 0x1d /* Ultra Technologies */ |
| |
|
#define | IFT_DS3 0x1e /* Generic T3 */ |
| |
|
#define | IFT_SIP 0x1f /* SMDS */ |
| |
|
#define | IFT_FRELAY 0x20 /* Frame Relay DTE only */ |
| |
|
#define | IFT_RS232 0x21 |
| |
|
#define | IFT_PARA 0x22 /* parallel-port */ |
| |
|
#define | IFT_ARCNET 0x23 |
| |
|
#define | IFT_ARCNETPLUS 0x24 |
| |
|
#define | IFT_ATM 0x25 /* ATM cells */ |
| |
|
#define | IFT_MIOX25 0x26 |
| |
|
#define | IFT_SONET 0x27 /* SONET or SDH */ |
| |
|
#define | IFT_X25PLE 0x28 |
| |
|
#define | IFT_ISO88022LLC 0x29 |
| |
|
#define | IFT_LOCALTALK 0x2a |
| |
|
#define | IFT_SMDSDXI 0x2b |
| |
|
#define | IFT_FRELAYDCE 0x2c /* Frame Relay DCE */ |
| |
|
#define | IFT_V35 0x2d |
| |
|
#define | IFT_HSSI 0x2e |
| |
|
#define | IFT_HIPPI 0x2f |
| |
|
#define | IFT_MODEM 0x30 /* Generic Modem */ |
| |
|
#define | IFT_AAL5 0x31 /* AAL5 over ATM */ |
| |
|
#define | IFT_SONETPATH 0x32 |
| |
|
#define | IFT_SONETVT 0x33 |
| |
|
#define | IFT_SMDSICIP 0x34 /* SMDS InterCarrier Interface */ |
| |
|
#define | IFT_PROPVIRTUAL 0x35 /* Proprietary Virtual/internal */ |
| |
|
#define | IFT_PROPMUX 0x36 /* Proprietary Multiplexing */ |
| |
|
#define | IFT_IEEE80212 0x37 /* 100BaseVG */ |
| |
|
#define | IFT_FIBRECHANNEL 0x38 /* Fibre Channel */ |
| |
|
#define | IFT_HIPPIINTERFACE 0x39 /* HIPPI interfaces */ |
| |
|
#define | IFT_FRAMERELAYINTERCONNECT 0x3a /* Obsolete, use either 0x20 or 0x2c */ |
| |
|
#define | IFT_AFLANE8023 0x3b /* ATM Emulated LAN for 802.3 */ |
| |
|
#define | IFT_AFLANE8025 0x3c /* ATM Emulated LAN for 802.5 */ |
| |
|
#define | IFT_CCTEMUL 0x3d /* ATM Emulated circuit */ |
| |
|
#define | IFT_FASTETHER 0x3e /* Fast Ethernet (100BaseT) */ |
| |
|
#define | IFT_ISDN 0x3f /* ISDN and X.25 */ |
| |
|
#define | IFT_V11 0x40 /* CCITT V.11/X.21 */ |
| |
|
#define | IFT_V36 0x41 /* CCITT V.36 */ |
| |
|
#define | IFT_G703AT64K 0x42 /* CCITT G703 at 64Kbps */ |
| |
|
#define | IFT_G703AT2MB 0x43 /* Obsolete see DS1-MIB */ |
| |
|
#define | IFT_QLLC 0x44 /* SNA QLLC */ |
| |
|
#define | IFT_FASTETHERFX 0x45 /* Fast Ethernet (100BaseFX) */ |
| |
|
#define | IFT_CHANNEL 0x46 /* channel */ |
| |
|
#define | IFT_IEEE80211 0x47 /* radio spread spectrum */ |
| |
|
#define | IFT_IBM370PARCHAN 0x48 /* IBM System 360/370 OEMI Channel */ |
| |
|
#define | IFT_ESCON 0x49 /* IBM Enterprise Systems Connection */ |
| |
|
#define | IFT_DLSW 0x4a /* Data Link Switching */ |
| |
|
#define | IFT_ISDNS 0x4b /* ISDN S/T interface */ |
| |
|
#define | IFT_ISDNU 0x4c /* ISDN U interface */ |
| |
|
#define | IFT_LAPD 0x4d /* Link Access Protocol D */ |
| |
|
#define | IFT_IPSWITCH 0x4e /* IP Switching Objects */ |
| |
|
#define | IFT_RSRB 0x4f /* Remote Source Route Bridging */ |
| |
|
#define | IFT_ATMLOGICAL 0x50 /* ATM Logical Port */ |
| |
|
#define | IFT_DS0 0x51 /* Digital Signal Level 0 */ |
| |
|
#define | IFT_DS0BUNDLE 0x52 /* group of ds0s on the same ds1 */ |
| |
|
#define | IFT_BSC 0x53 /* Bisynchronous Protocol */ |
| |
|
#define | IFT_ASYNC 0x54 /* Asynchronous Protocol */ |
| |
|
#define | IFT_CNR 0x55 /* Combat Net Radio */ |
| |
|
#define | IFT_ISO88025DTR 0x56 /* ISO 802.5r DTR */ |
| |
|
#define | IFT_EPLRS 0x57 /* Ext Pos Loc Report Sys */ |
| |
|
#define | IFT_ARAP 0x58 /* Appletalk Remote Access Protocol */ |
| |
|
#define | IFT_PROPCNLS 0x59 /* Proprietary Connectionless Protocol*/ |
| |
|
#define | IFT_HOSTPAD 0x5a /* CCITT-ITU X.29 PAD Protocol */ |
| |
|
#define | IFT_TERMPAD 0x5b /* CCITT-ITU X.3 PAD Facility */ |
| |
|
#define | IFT_FRAMERELAYMPI 0x5c /* Multiproto Interconnect over FR */ |
| |
|
#define | IFT_X213 0x5d /* CCITT-ITU X213 */ |
| |
|
#define | IFT_ADSL 0x5e /* Asymmetric Digital Subscriber Loop */ |
| |
|
#define | IFT_RADSL 0x5f /* Rate-Adapt. Digital Subscriber Loop*/ |
| |
|
#define | IFT_SDSL 0x60 /* Symmetric Digital Subscriber Loop */ |
| |
|
#define | IFT_VDSL 0x61 /* Very H-Speed Digital Subscrib. Loop*/ |
| |
|
#define | IFT_ISO88025CRFPINT 0x62 /* ISO 802.5 CRFP */ |
| |
|
#define | IFT_MYRINET 0x63 /* Myricom Myrinet */ |
| |
|
#define | IFT_VOICEEM 0x64 /* voice recEive and transMit */ |
| |
|
#define | IFT_VOICEFXO 0x65 /* voice Foreign Exchange Office */ |
| |
|
#define | IFT_VOICEFXS 0x66 /* voice Foreign Exchange Station */ |
| |
|
#define | IFT_VOICEENCAP 0x67 /* voice encapsulation */ |
| |
|
#define | IFT_VOICEOVERIP 0x68 /* voice over IP encapsulation */ |
| |
|
#define | IFT_ATMDXI 0x69 /* ATM DXI */ |
| |
|
#define | IFT_ATMFUNI 0x6a /* ATM FUNI */ |
| |
|
#define | IFT_ATMIMA 0x6b /* ATM IMA */ |
| |
|
#define | IFT_PPPMULTILINKBUNDLE 0x6c /* PPP Multilink Bundle */ |
| |
|
#define | IFT_IPOVERCDLC 0x6d /* IBM ipOverCdlc */ |
| |
|
#define | IFT_IPOVERCLAW 0x6e /* IBM Common Link Access to Workstn */ |
| |
|
#define | IFT_STACKTOSTACK 0x6f /* IBM stackToStack */ |
| |
|
#define | IFT_VIRTUALIPADDRESS 0x70 /* IBM VIPA */ |
| |
|
#define | IFT_MPC 0x71 /* IBM multi-protocol channel support */ |
| |
|
#define | IFT_IPOVERATM 0x72 /* IBM ipOverAtm */ |
| |
|
#define | IFT_ISO88025FIBER 0x73 /* ISO 802.5j Fiber Token Ring */ |
| |
|
#define | IFT_TDLC 0x74 /* IBM twinaxial data link control */ |
| |
|
#define | IFT_GIGABITETHERNET 0x75 /* Gigabit Ethernet */ |
| |
|
#define | IFT_HDLC 0x76 /* HDLC */ |
| |
|
#define | IFT_LAPF 0x77 /* LAP F */ |
| |
|
#define | IFT_V37 0x78 /* V.37 */ |
| |
|
#define | IFT_X25MLP 0x79 /* Multi-Link Protocol */ |
| |
|
#define | IFT_X25HUNTGROUP 0x7a /* X25 Hunt Group */ |
| |
|
#define | IFT_TRANSPHDLC 0x7b /* Transp HDLC */ |
| |
|
#define | IFT_INTERLEAVE 0x7c /* Interleave channel */ |
| |
|
#define | IFT_FAST 0x7d /* Fast channel */ |
| |
|
#define | IFT_IP 0x7e /* IP (for APPN HPR in IP networks) */ |
| |
|
#define | IFT_DOCSCABLEMACLAYER 0x7f /* CATV Mac Layer */ |
| |
|
#define | IFT_DOCSCABLEDOWNSTREAM 0x80 /* CATV Downstream interface */ |
| |
|
#define | IFT_DOCSCABLEUPSTREAM 0x81 /* CATV Upstream interface */ |
| |
|
#define | IFT_A12MPPSWITCH 0x82 /* Avalon Parallel Processor */ |
| |
|
#define | IFT_TUNNEL 0x83 /* Encapsulation interface */ |
| |
|
#define | IFT_COFFEE 0x84 /* coffee pot */ |
| |
|
#define | IFT_CES 0x85 /* Circiut Emulation Service */ |
| |
|
#define | IFT_ATMSUBINTERFACE 0x86 /* (x) ATM Sub Interface */ |
| |
|
#define | IFT_L2VLAN 0x87 /* Layer 2 Virtual LAN using 802.1Q */ |
| |
|
#define | IFT_L3IPVLAN 0x88 /* Layer 3 Virtual LAN - IP Protocol */ |
| |
|
#define | IFT_L3IPXVLAN 0x89 /* Layer 3 Virtual LAN - IPX Prot. */ |
| |
|
#define | IFT_DIGITALPOWERLINE 0x8a /* IP over Power Lines */ |
| |
|
#define | IFT_MEDIAMAILOVERIP 0x8b /* (xxx) Multimedia Mail over IP */ |
| |
|
#define | IFT_DTM 0x8c /* Dynamic synchronous Transfer Mode */ |
| |
|
#define | IFT_DCN 0x8d /* Data Communications Network */ |
| |
|
#define | IFT_IPFORWARD 0x8e /* IP Forwarding Interface */ |
| |
|
#define | IFT_MSDSL 0x8f /* Multi-rate Symmetric DSL */ |
| |
|
#define | IFT_IEEE1394 0x90 /* IEEE1394 High Performance SerialBus*/ |
| |
|
#define | IFT_IFGSN 0x91 /* HIPPI-6400 */ |
| |
|
#define | IFT_DVBRCCMACLAYER 0x92 /* DVB-RCC MAC Layer */ |
| |
|
#define | IFT_DVBRCCDOWNSTREAM 0x93 /* DVB-RCC Downstream Channel */ |
| |
|
#define | IFT_DVBRCCUPSTREAM 0x94 /* DVB-RCC Upstream Channel */ |
| |
|
#define | IFT_ATMVIRTUAL 0x95 /* ATM Virtual Interface */ |
| |
|
#define | IFT_MPLSTUNNEL 0x96 /* MPLS Tunnel Virtual Interface */ |
| |
|
#define | IFT_SRP 0x97 /* Spatial Reuse Protocol */ |
| |
|
#define | IFT_VOICEOVERATM 0x98 /* Voice over ATM */ |
| |
|
#define | IFT_VOICEOVERFRAMERELAY 0x99 /* Voice Over Frame Relay */ |
| |
|
#define | IFT_IDSL 0x9a /* Digital Subscriber Loop over ISDN */ |
| |
|
#define | IFT_COMPOSITELINK 0x9b /* Avici Composite Link Interface */ |
| |
|
#define | IFT_SS7SIGLINK 0x9c /* SS7 Signaling Link */ |
| |
|
#define | IFT_PROPWIRELESSP2P 0x9d /* Prop. P2P wireless interface */ |
| |
|
#define | IFT_FRFORWARD 0x9e /* Frame forward Interface */ |
| |
|
#define | IFT_RFC1483 0x9f /* Multiprotocol over ATM AAL5 */ |
| |
|
#define | IFT_USB 0xa0 /* USB Interface */ |
| |
|
#define | IFT_IEEE8023ADLAG 0xa1 /* IEEE 802.3ad Link Aggregate*/ |
| |
|
#define | IFT_BGPPOLICYACCOUNTING 0xa2 /* BGP Policy Accounting */ |
| |
|
#define | IFT_FRF16MFRBUNDLE 0xa3 /* FRF.16 Multilik Frame Relay*/ |
| |
|
#define | IFT_H323GATEKEEPER 0xa4 /* H323 Gatekeeper */ |
| |
|
#define | IFT_H323PROXY 0xa5 /* H323 Voice and Video Proxy */ |
| |
|
#define | IFT_MPLS 0xa6 /* MPLS */ |
| |
|
#define | IFT_MFSIGLINK 0xa7 /* Multi-frequency signaling link */ |
| |
|
#define | IFT_HDSL2 0xa8 /* High Bit-Rate DSL, 2nd gen. */ |
| |
|
#define | IFT_SHDSL 0xa9 /* Multirate HDSL2 */ |
| |
|
#define | IFT_DS1FDL 0xaa /* Facility Data Link (4Kbps) on a DS1*/ |
| |
|
#define | IFT_POS 0xab /* Packet over SONET/SDH Interface */ |
| |
|
#define | IFT_DVBASILN 0xac /* DVB-ASI Input */ |
| |
|
#define | IFT_DVBASIOUT 0xad /* DVB-ASI Output */ |
| |
|
#define | IFT_PLC 0xae /* Power Line Communications */ |
| |
|
#define | IFT_NFAS 0xaf /* Non-Facility Associated Signaling */ |
| |
|
#define | IFT_TR008 0xb0 /* TROO8 */ |
| |
|
#define | IFT_GR303RDT 0xb1 /* Remote Digital Terminal */ |
| |
|
#define | IFT_GR303IDT 0xb2 /* Integrated Digital Terminal */ |
| |
|
#define | IFT_ISUP 0xb3 /* ISUP */ |
| |
|
#define | IFT_PROPDOCSWIRELESSMACLAYER 0xb4 /* prop/Wireless MAC Layer */ |
| |
|
#define | IFT_PROPDOCSWIRELESSDOWNSTREAM 0xb5 /* prop/Wireless Downstream */ |
| |
|
#define | IFT_PROPDOCSWIRELESSUPSTREAM 0xb6 /* prop/Wireless Upstream */ |
| |
|
#define | IFT_HIPERLAN2 0xb7 /* HIPERLAN Type 2 Radio Interface */ |
| |
|
#define | IFT_PROPBWAP2MP 0xb8 /* PropBroadbandWirelessAccess P2MP*/ |
| |
|
#define | IFT_SONETOVERHEADCHANNEL 0xb9 /* SONET Overhead Channel */ |
| |
|
#define | IFT_DIGITALWRAPPEROVERHEADCHANNEL 0xba /* Digital Wrapper Overhead */ |
| |
|
#define | IFT_AAL2 0xbb /* ATM adaptation layer 2 */ |
| |
|
#define | IFT_RADIOMAC 0xbc /* MAC layer over radio links */ |
| |
|
#define | IFT_ATMRADIO 0xbd /* ATM over radio links */ |
| |
|
#define | IFT_IMT 0xbe /* Inter-Machine Trunks */ |
| |
|
#define | IFT_MVL 0xbf /* Multiple Virtual Lines DSL */ |
| |
|
#define | IFT_REACHDSL 0xc0 /* Long Reach DSL */ |
| |
|
#define | IFT_FRDLCIENDPT 0xc1 /* Frame Relay DLCI End Point */ |
| |
|
#define | IFT_ATMVCIENDPT 0xc2 /* ATM VCI End Point */ |
| |
|
#define | IFT_OPTICALCHANNEL 0xc3 /* Optical Channel */ |
| |
|
#define | IFT_OPTICALTRANSPORT 0xc4 /* Optical Transport */ |
| |
|
#define | IFT_STF 0xd7 /* 6to4 interface */ |
| |
|
#define | IFT_GIF 0xf0 |
| |
|
#define | IFT_PVC 0xf1 |
| |
|
#define | IFT_FAITH 0xf2 |
| |
|
#define | IFT_PFLOG 0xf6 |
| |
|
#define | IFT_PFSYNC 0xf7 |
| |
|
#define | IFT_CARP 0xf8 /* Common Address Redundancy Protocol */ |
| |
