#define | ETHER_ADDR_LEN 6 /* length of an Ethernet address */ |
| |
|
#define | ETHER_TYPE_LEN 2 /* length of the Ethernet type field */ |
| |
|
#define | ETHER_CRC_LEN 4 /* length of the Ethernet CRC */ |
| |
|
#define | ETHER_HDR_LEN (ETHER_ADDR_LEN*2+ETHER_TYPE_LEN) |
| |
|
#define | ETHER_MIN_LEN 64 /* minimum frame len, including CRC */ |
| |
|
#define | ETHER_MAX_LEN 1518 /* maximum frame len, including CRC */ |
| |
|
#define | ETHER_MAX_LEN_JUMBO 9018 /* max jumbo frame len, including CRC */ |
| |
|
#define | ETHER_VLAN_ENCAP_LEN 4 /* len of 802.1Q VLAN encapsulation */ |
| |
|
#define | ETHER_ALIGN 2 /* driver adjust for IP hdr alignment */ |
| |
| #define | ETHER_MAX_FRAME(ifp, etype, hasfcs) |
| |
|
#define | M_HASFCS M_PROTO5 /* FCS included at end of frame */ |
| |
|
#define | ETHER_CRC_POLY_LE 0xedb88320 |
| |
|
#define | ETHER_CRC_POLY_BE 0x04c11db6 |
| |
|
#define | ETHER_IS_VALID_LEN(foo) ((foo) >= ETHER_MIN_LEN && (foo) <= ETHER_MAX_LEN) |
| |
|
#define | ETHER_IS_MULTICAST(addr) (*(addr) & 0x01) /* is address mcast/bcast? */ |
| |
|
#define | ETHERTYPE_8023 0x0004 /* IEEE 802.3 packet */ |
| |
|
#define | ETHERTYPE_PUP 0x0200 /* Xerox PUP protocol - see 0A00 */ |
| |
|
#define | ETHERTYPE_PUPAT 0x0200 /* PUP Address Translation - see 0A01 */ |
| |
|
#define | ETHERTYPE_SPRITE 0x0500 /* ??? */ |
| |
|
#define | ETHERTYPE_NS 0x0600 /* XNS */ |
| |
|
#define | ETHERTYPE_NSAT 0x0601 /* XNS Address Translation (3Mb only) */ |
| |
|
#define | ETHERTYPE_DLOG1 0x0660 /* DLOG (?) */ |
| |
|
#define | ETHERTYPE_DLOG2 0x0661 /* DLOG (?) */ |
| |
|
#define | ETHERTYPE_IP 0x0800 /* IP protocol */ |
| |
|
#define | ETHERTYPE_X75 0x0801 /* X.75 Internet */ |
| |
|
#define | ETHERTYPE_NBS 0x0802 /* NBS Internet */ |
| |
|
#define | ETHERTYPE_ECMA 0x0803 /* ECMA Internet */ |
| |
|
#define | ETHERTYPE_CHAOS 0x0804 /* CHAOSnet */ |
| |
|
#define | ETHERTYPE_X25 0x0805 /* X.25 Level 3 */ |
| |
|
#define | ETHERTYPE_ARP 0x0806 /* Address resolution protocol */ |
| |
|
#define | ETHERTYPE_NSCOMPAT 0x0807 /* XNS Compatibility */ |
| |
|
#define | ETHERTYPE_FRARP 0x0808 /* Frame Relay ARP (RFC1701) */ |
| |
|
#define | ETHERTYPE_UBDEBUG 0x0900 /* Ungermann-Bass network debugger */ |
| |
|
#define | ETHERTYPE_IEEEPUP 0x0A00 /* Xerox IEEE802.3 PUP */ |
| |
|
#define | ETHERTYPE_IEEEPUPAT 0x0A01 /* Xerox IEEE802.3 PUP Address Translation */ |
| |
|
#define | ETHERTYPE_VINES 0x0BAD /* Banyan VINES */ |
| |
|
#define | ETHERTYPE_VINESLOOP 0x0BAE /* Banyan VINES Loopback */ |
| |
|
#define | ETHERTYPE_VINESECHO 0x0BAF /* Banyan VINES Echo */ |
| |
|
#define | ETHERTYPE_TRAIL 0x1000 /* Trailer packet */ |
| |
|
#define | ETHERTYPE_NTRAILER 16 |
| |
|
#define | ETHERTYPE_DCA 0x1234 /* DCA - Multicast */ |
| |
|
#define | ETHERTYPE_VALID 0x1600 /* VALID system protocol */ |
| |
|
#define | ETHERTYPE_DOGFIGHT 0x1989 /* Artificial Horizons ("Aviator" dogfight simulator [on Sun]) */ |
| |
|
#define | ETHERTYPE_RCL 0x1995 /* Datapoint Corporation (RCL lan protocol) */ |
| |
|
#define | ETHERTYPE_NBPVCD 0x3C00 /* 3Com NBP virtual circuit datagram (like XNS SPP) not registered */ |
| |
|
#define | ETHERTYPE_NBPSCD 0x3C01 /* 3Com NBP System control datagram not registered */ |
| |
|
#define | ETHERTYPE_NBPCREQ 0x3C02 /* 3Com NBP Connect request (virtual cct) not registered */ |
| |
|
#define | ETHERTYPE_NBPCRSP 0x3C03 /* 3Com NBP Connect repsonse not registered */ |
| |
|
#define | ETHERTYPE_NBPCC 0x3C04 /* 3Com NBP Connect complete not registered */ |
| |
|
#define | ETHERTYPE_NBPCLREQ 0x3C05 /* 3Com NBP Close request (virtual cct) not registered */ |
| |
|
#define | ETHERTYPE_NBPCLRSP 0x3C06 /* 3Com NBP Close response not registered */ |
| |
|
#define | ETHERTYPE_NBPDG 0x3C07 /* 3Com NBP Datagram (like XNS IDP) not registered */ |
| |
|
#define | ETHERTYPE_NBPDGB 0x3C08 /* 3Com NBP Datagram broadcast not registered */ |
| |
|
#define | ETHERTYPE_NBPCLAIM 0x3C09 /* 3Com NBP Claim NetBIOS name not registered */ |
| |
|
#define | ETHERTYPE_NBPDLTE 0x3C0A /* 3Com NBP Delete Netbios name not registered */ |
| |
|
#define | ETHERTYPE_NBPRAS 0x3C0B /* 3Com NBP Remote adaptor status request not registered */ |
| |
|
#define | ETHERTYPE_NBPRAR 0x3C0C /* 3Com NBP Remote adaptor response not registered */ |
| |
|
#define | ETHERTYPE_NBPRST 0x3C0D /* 3Com NBP Reset not registered */ |
| |
|
#define | ETHERTYPE_PCS 0x4242 /* PCS Basic Block Protocol */ |
| |
|
#define | ETHERTYPE_IMLBLDIAG 0x424C /* Information Modes Little Big LAN diagnostic */ |
| |
|
#define | ETHERTYPE_DIDDLE 0x4321 /* THD - Diddle */ |
| |
|
#define | ETHERTYPE_IMLBL 0x4C42 /* Information Modes Little Big LAN */ |
| |
|
#define | ETHERTYPE_SIMNET 0x5208 /* BBN Simnet Private */ |
| |
|
#define | ETHERTYPE_DECEXPER 0x6000 /* DEC Unassigned, experimental */ |
| |
|
#define | ETHERTYPE_MOPDL 0x6001 /* DEC MOP dump/load */ |
| |
|
#define | ETHERTYPE_MOPRC 0x6002 /* DEC MOP remote console */ |
| |
|
#define | ETHERTYPE_DECnet 0x6003 /* DEC DECNET Phase IV route */ |
| |
|
#define | ETHERTYPE_DN ETHERTYPE_DECnet /* libpcap, tcpdump */ |
| |
|
#define | ETHERTYPE_LAT 0x6004 /* DEC LAT */ |
| |
|
#define | ETHERTYPE_DECDIAG 0x6005 /* DEC diagnostic protocol (at interface initialization?) */ |
| |
|
#define | ETHERTYPE_DECCUST 0x6006 /* DEC customer protocol */ |
| |
|
#define | ETHERTYPE_SCA 0x6007 /* DEC LAVC, SCA */ |
| |
|
#define | ETHERTYPE_AMBER 0x6008 /* DEC AMBER */ |
| |
|
#define | ETHERTYPE_DECMUMPS 0x6009 /* DEC MUMPS */ |
| |
|
#define | ETHERTYPE_TRANSETHER 0x6558 /* Trans Ether Bridging (RFC1701)*/ |
| |
|
#define | ETHERTYPE_RAWFR 0x6559 /* Raw Frame Relay (RFC1701) */ |
| |
|
#define | ETHERTYPE_UBDL 0x7000 /* Ungermann-Bass download */ |
| |
|
#define | ETHERTYPE_UBNIU 0x7001 /* Ungermann-Bass NIUs */ |
| |
|
#define | ETHERTYPE_UBDIAGLOOP 0x7002 /* Ungermann-Bass diagnostic/loopback */ |
| |
|
#define | ETHERTYPE_UBNMC 0x7003 /* Ungermann-Bass ??? (NMC to/from UB Bridge) */ |
| |
|
#define | ETHERTYPE_UBBST 0x7005 /* Ungermann-Bass Bridge Spanning Tree */ |
| |
|
#define | ETHERTYPE_OS9 0x7007 /* OS/9 Microware */ |
| |
|
#define | ETHERTYPE_OS9NET 0x7009 /* OS/9 Net? */ |
| |
|
#define | ETHERTYPE_RACAL 0x7030 /* Racal-Interlan */ |
| |
|
#define | ETHERTYPE_PRIMENTS 0x7031 /* Prime NTS (Network Terminal Service) */ |
| |
|
#define | ETHERTYPE_CABLETRON 0x7034 /* Cabletron */ |
| |
|
#define | ETHERTYPE_CRONUSVLN 0x8003 /* Cronus VLN */ |
| |
|
#define | ETHERTYPE_CRONUS 0x8004 /* Cronus Direct */ |
| |
|
#define | ETHERTYPE_HP 0x8005 /* HP Probe */ |
| |
|
#define | ETHERTYPE_NESTAR 0x8006 /* Nestar */ |
| |
|
#define | ETHERTYPE_ATTSTANFORD 0x8008 /* AT&T/Stanford (local use) */ |
| |
|
#define | ETHERTYPE_EXCELAN 0x8010 /* Excelan */ |
| |
|
#define | ETHERTYPE_SG_DIAG 0x8013 /* SGI diagnostic type */ |
| |
|
#define | ETHERTYPE_SG_NETGAMES 0x8014 /* SGI network games */ |
| |
|
#define | ETHERTYPE_SG_RESV 0x8015 /* SGI reserved type */ |
| |
|
#define | ETHERTYPE_SG_BOUNCE 0x8016 /* SGI bounce server */ |
| |
|
#define | ETHERTYPE_APOLLODOMAIN 0x8019 /* Apollo DOMAIN */ |
| |
|
#define | ETHERTYPE_TYMSHARE 0x802E /* Tymeshare */ |
| |
|
#define | ETHERTYPE_TIGAN 0x802F /* Tigan, Inc. */ |
| |
|
#define | ETHERTYPE_REVARP 0x8035 /* Reverse addr resolution protocol */ |
| |
|
#define | ETHERTYPE_AEONIC 0x8036 /* Aeonic Systems */ |
| |
|
#define | ETHERTYPE_IPXNEW 0x8037 /* IPX (Novell Netware?) */ |
| |
|
#define | ETHERTYPE_LANBRIDGE 0x8038 /* DEC LANBridge */ |
| |
|
#define | ETHERTYPE_DSMD 0x8039 /* DEC DSM/DDP */ |
| |
|
#define | ETHERTYPE_ARGONAUT 0x803A /* DEC Argonaut Console */ |
| |
|
#define | ETHERTYPE_VAXELN 0x803B /* DEC VAXELN */ |
| |
|
#define | ETHERTYPE_DECDNS 0x803C /* DEC DNS Naming Service */ |
| |
|
#define | ETHERTYPE_ENCRYPT 0x803D /* DEC Ethernet Encryption */ |
| |
|
#define | ETHERTYPE_DECDTS 0x803E /* DEC Distributed Time Service */ |
| |
|
#define | ETHERTYPE_DECLTM 0x803F /* DEC LAN Traffic Monitor */ |
| |
|
#define | ETHERTYPE_DECNETBIOS 0x8040 /* DEC PATHWORKS DECnet NETBIOS Emulation */ |
| |
|
#define | ETHERTYPE_DECLAST 0x8041 /* DEC Local Area System Transport */ |
| |
|
#define | ETHERTYPE_PLANNING 0x8044 /* Planning Research Corp. */ |
| |
|
#define | ETHERTYPE_DECAM 0x8048 /* DEC Availability Manager for Distributed Systems DECamds (but someone at DEC says not) */ |
| |
|
#define | ETHERTYPE_EXPERDATA 0x8049 /* ExperData */ |
| |
|
#define | ETHERTYPE_VEXP 0x805B /* Stanford V Kernel exp. */ |
| |
|
#define | ETHERTYPE_VPROD 0x805C /* Stanford V Kernel prod. */ |
| |
|
#define | ETHERTYPE_ES 0x805D /* Evans & Sutherland */ |
| |
|
#define | ETHERTYPE_LITTLE 0x8060 /* Little Machines */ |
| |
|
#define | ETHERTYPE_COUNTERPOINT 0x8062 /* Counterpoint Computers */ |
| |
|
#define | ETHERTYPE_VEECO 0x8067 /* Veeco Integrated Auto. */ |
| |
|
#define | ETHERTYPE_GENDYN 0x8068 /* General Dynamics */ |
| |
|
#define | ETHERTYPE_ATT 0x8069 /* AT&T */ |
| |
|
#define | ETHERTYPE_AUTOPHON 0x806A /* Autophon */ |
| |
|
#define | ETHERTYPE_COMDESIGN 0x806C /* ComDesign */ |
| |
|
#define | ETHERTYPE_COMPUGRAPHIC 0x806D /* Compugraphic Corporation */ |
| |
|
#define | ETHERTYPE_MATRA 0x807A /* Matra */ |
| |
|
#define | ETHERTYPE_DDE 0x807B /* Dansk Data Elektronik */ |
| |
|
#define | ETHERTYPE_MERIT 0x807C /* Merit Internodal (or Univ of Michigan?) */ |
| |
|
#define | ETHERTYPE_VLTLMAN 0x8080 /* Vitalink TransLAN III Management */ |
| |
|
#define | ETHERTYPE_ATALK 0x809B /* AppleTalk */ |
| |
|
#define | ETHERTYPE_AT ETHERTYPE_ATALK /* old NetBSD */ |
| |
|
#define | ETHERTYPE_APPLETALK ETHERTYPE_ATALK /* HP-UX */ |
| |
|
#define | ETHERTYPE_SPIDER 0x809F /* Spider Systems Ltd. */ |
| |
|
#define | ETHERTYPE_PACER 0x80C6 /* Pacer Software */ |
| |
|
#define | ETHERTYPE_APPLITEK 0x80C7 /* Applitek Corporation */ |
| |
|
#define | ETHERTYPE_SNA 0x80D5 /* IBM SNA Services over Ethernet */ |
| |
|
#define | ETHERTYPE_VARIAN 0x80DD /* Varian Associates */ |
| |
|
#define | ETHERTYPE_RETIX 0x80F2 /* Retix */ |
| |
|
#define | ETHERTYPE_AARP 0x80F3 /* AppleTalk AARP */ |
| |
|
#define | ETHERTYPE_APOLLO 0x80F7 /* Apollo Computer */ |
| |
|
#define | ETHERTYPE_VLAN 0x8100 /* IEEE 802.1Q VLAN tagging (XXX conflicts) */ |
| |
|
#define | ETHERTYPE_BOFL 0x8102 /* Wellfleet; BOFL (Breath OF Life) pkts [every 5-10 secs.] */ |
| |
|
#define | ETHERTYPE_WELLFLEET 0x8103 /* Wellfleet Communications */ |
| |
|
#define | ETHERTYPE_TALARIS 0x812B /* Talaris */ |
| |
|
#define | ETHERTYPE_WATERLOO 0x8130 /* Waterloo Microsystems Inc. (XXX which?) */ |
| |
|
#define | ETHERTYPE_HAYES 0x8130 /* Hayes Microcomputers (XXX which?) */ |
| |
|
#define | ETHERTYPE_VGLAB 0x8131 /* VG Laboratory Systems */ |
| |
|
#define | ETHERTYPE_IPX 0x8137 /* Novell (old) NetWare IPX (ECONFIG E option) */ |
| |
|
#define | ETHERTYPE_NOVELL 0x8138 /* Novell, Inc. */ |
| |
|
#define | ETHERTYPE_MUMPS 0x813F /* M/MUMPS data sharing */ |
| |
|
#define | ETHERTYPE_AMOEBA 0x8145 /* Vrije Universiteit (NL) Amoeba 4 RPC (obsolete) */ |
| |
|
#define | ETHERTYPE_FLIP 0x8146 /* Vrije Universiteit (NL) FLIP (Fast Local Internet Protocol) */ |
| |
|
#define | ETHERTYPE_VURESERVED 0x8147 /* Vrije Universiteit (NL) [reserved] */ |
| |
|
#define | ETHERTYPE_LOGICRAFT 0x8148 /* Logicraft */ |
| |
|
#define | ETHERTYPE_NCD 0x8149 /* Network Computing Devices */ |
| |
|
#define | ETHERTYPE_ALPHA 0x814A /* Alpha Micro */ |
| |
|
#define | ETHERTYPE_SNMP 0x814C /* SNMP over Ethernet (see RFC1089) */ |
| |
|
#define | ETHERTYPE_TEC 0x814F /* Technically Elite Concepts */ |
| |
|
#define | ETHERTYPE_RATIONAL 0x8150 /* Rational Corp */ |
| |
|
#define | ETHERTYPE_XTP 0x817D /* Protocol Engines XTP */ |
| |
|
#define | ETHERTYPE_SGITW 0x817E /* SGI/Time Warner prop. */ |
| |
|
#define | ETHERTYPE_HIPPI_FP 0x8180 /* HIPPI-FP encapsulation */ |
| |
|
#define | ETHERTYPE_STP 0x8181 /* Scheduled Transfer STP, HIPPI-ST */ |
| |
|
#define | ETHERTYPE_MOTOROLA 0x818D /* Motorola */ |
| |
|
#define | ETHERTYPE_NETBEUI 0x8191 /* PowerLAN NetBIOS/NetBEUI (PC) */ |
| |
|
#define | ETHERTYPE_ACCTON 0x8390 /* Accton Technologies (unregistered) */ |
| |
|
#define | ETHERTYPE_TALARISMC 0x852B /* Talaris multicast */ |
| |
|
#define | ETHERTYPE_KALPANA 0x8582 /* Kalpana */ |
| |
|
#define | ETHERTYPE_SECTRA 0x86DB /* SECTRA */ |
| |
|
#define | ETHERTYPE_IPV6 0x86DD /* IP protocol version 6 */ |
| |
|
#define | ETHERTYPE_DELTACON 0x86DE /* Delta Controls */ |
| |
|
#define | ETHERTYPE_ATOMIC 0x86DF /* ATOMIC */ |
| |
|
#define | ETHERTYPE_RDP 0x8739 /* Control Technology Inc. RDP Without IP */ |
| |
|
#define | ETHERTYPE_MICP 0x873A /* Control Technology Inc. Mcast Industrial Ctrl Proto. */ |
| |
|
#define | ETHERTYPE_TCPCOMP 0x876B /* TCP/IP Compression (RFC1701) */ |
| |
|
#define | ETHERTYPE_IPAS 0x876C /* IP Autonomous Systems (RFC1701) */ |
| |
|
#define | ETHERTYPE_SECUREDATA 0x876D /* Secure Data (RFC1701) */ |
| |
|
#define | ETHERTYPE_FLOWCONTROL 0x8808 /* 802.3x flow control packet */ |
| |
|
#define | ETHERTYPE_PPP 0x880B /* PPP (obsolete by PPPOE) */ |
| |
|
#define | ETHERTYPE_HITACHI 0x8820 /* Hitachi Cable (Optoelectronic Systems Laboratory) */ |
| |
|
#define | ETHERTYPE_MPLS 0x8847 /* MPLS Unicast */ |
| |
|
#define | ETHERTYPE_MPLS_MCAST 0x8848 /* MPLS Multicast */ |
| |
|
#define | ETHERTYPE_AXIS 0x8856 /* Axis Communications AB proprietary bootstrap/config */ |
| |
|
#define | ETHERTYPE_PPPOEDISC 0x8863 /* PPP Over Ethernet Discovery Stage */ |
| |
|
#define | ETHERTYPE_PPPOE 0x8864 /* PPP Over Ethernet Session Stage */ |
| |
|
#define | ETHERTYPE_LANPROBE 0x8888 /* HP LanProbe test? */ |
| |
|
#define | ETHERTYPE_PAE 0x888e /* EAPOL PAE/802.1x */ |
| |
|
#define | ETHERTYPE_LOOPBACK 0x9000 /* Loopback: used to test interfaces */ |
| |
|
#define | ETHERTYPE_LBACK ETHERTYPE_LOOPBACK /* DEC MOP loopback */ |
| |
|
#define | ETHERTYPE_XNSSM 0x9001 /* 3Com (Formerly Bridge Communications), XNS Systems Management */ |
| |
|
#define | ETHERTYPE_TCPSM 0x9002 /* 3Com (Formerly Bridge Communications), TCP/IP Systems Management */ |
| |
|
#define | ETHERTYPE_BCLOOP 0x9003 /* 3Com (Formerly Bridge Communications), loopback detection */ |
| |
|
#define | ETHERTYPE_DEBNI 0xAAAA /* DECNET? Used by VAX 6220 DEBNI */ |
| |
|
#define | ETHERTYPE_SONIX 0xFAF5 /* Sonix Arpeggio */ |
| |
|
#define | ETHERTYPE_VITAL 0xFF00 /* BBN VITAL-LanBridge cache wakeups */ |
| |
|
#define | ETHERTYPE_MAX 0xFFFF /* Maximum valid ethernet type, reserved */ |
| |
|
#define | ETHERTYPE_TRAIL 0x1000 /* Trailer packet */ |
| |
|
#define | ETHERTYPE_NTRAILER 16 |
| |
|
#define | ETHERMTU (ETHER_MAX_LEN-ETHER_HDR_LEN-ETHER_CRC_LEN) |
| |
|
#define | ETHERMIN (ETHER_MIN_LEN-ETHER_HDR_LEN-ETHER_CRC_LEN) |
| |
|
#define | ETHERMTU_JUMBO (ETHER_MAX_LEN_JUMBO - ETHER_HDR_LEN - ETHER_CRC_LEN) |
| |
